Altair Embed: Real-Time Model-Based Design for Embedded Systems
Altair Embed is a sophisticated model-based development tool designed especially for embedded systems that allows engineers to graphically build algorithms and run them directly on target hardware. Whether you are building control systems, sensor interfaces, or motor controllers, Altair Embed provides an efficiency-packed environment that eases simulation, code generation, and hardware deployment from one platform alone.
In this article, we’ll dive deep into Altair Embed, its key features, benefits, use cases, and why it’s becoming an essential tool in embedded system development.
What Is Altair Embed?
Altair Embed is a model-based development software for embedded control systems. It enables system-level models to be created and simulated by developers and, from these models, automatically code high-quality C code to run on a wide range of microcontrollers and digital signal processors (DSPs).
Unlike other coding methods that involve extensive manual implementation and testing, Altair Embed speeds up development by assisting engineers in graphically creating, simulating real-world behavior, and generating embedded-ready code with a click of the mouse.
Features of Altair Embed
- Graphical Modeling Environment
Altair Embed utilizes the block diagram approach, which simplifies the modeling of systems without requiring manual coding of complex software. Engineers can visually build control and logic systems through dragging and dropping functional blocks into position, accelerating development time and reducing errors. - Real-Time Simulation
Perhaps the most impressive feature of Altair Embed is its ability to run real-time simulations with hardware attached. This allows developers to test, calibrate, and debug embedded algorithms in real-time, ensuring accuracy and reducing development cycles. - Automatic Code Generation
Altair Embed directly converts your visual model into optimized ANSI C code, ready to execute on your host microcontroller. This eliminates the manual coding of the logic, which reduces bugs and enhances consistency.
Hardware platforms that are supported:
Texas Instruments (TI) C2000, MSP430, and ARM Cortex-M chips
STMicroelectronics STM32 family
Arduino
Raspberry Pi
And many others
- Hardware-In-the-Loop (HIL) Testing
Embed supports hardware-in-the-loop testing, so your virtual models can talk to real hardware in real time. This is especially useful for control system validation and ensuring performance in real-world applications. - Enormous Libraries and Toolboxes
Altair Embed has libraries for:
Control systems
Signal processing
Communications
Motor control
Power electronics
Sensors and actuators
These ready-to-use components allow engineers to create complex systems quickly and accurately.
Benefits of Using Altair Embed
✔ Reduced Development Cycles
Model-based design minimizes development time. Simulation before release allows teams to catch issues early, eliminating costly failures later on.
✔ High Quality of Generated Code
Automatically generated code is consistent, optimized, and generally more efficient than code written by hand—especially for resource-restricted embedded hardware.
✔ Testing Time Minimized
Real-time simulation and HIL testing allow you to validate systems long before hardware is decided, allowing the development process to be more agile and responsive.
✔ Debugging Simplified
Altair Embed is shipped with debugging features such as scopes, plots, and real-time parameter adjustment. These make it simple to use for monitoring performance and instantly making adjustments.
✔ Ideal for Education and Prototyping
Its graphical modeling interface and ease of use make Embed an excellent learning and prototyping platform for students and researchers wanting to play around with embedded systems and control logic.
Typical Applications
Altair Embed enjoys wide industry coverage in automotive, aerospace, consumer products, and renewable energy. Some typical applications include:
Motor control (DC, BLDC, stepper)
Sensor interfacing and filtering
PID and adaptive control systems
Power supply and converter design
IoT edge device prototyping
Signal processing algorithms
Since it supports an extremely large number of microcontrollers and processors, it’s also an excellent platform for rapid prototyping and low-cost development.
Altair Embed vs. Traditional Coding
Traditional embedded systems development is generally accomplished by coding long blocks of C or assembly code, hand-debugging, and flashing the code to experiment with performance. This is tedious and error-prone.
With Altair Embed, you can:
Eliminate cumbersome coding cycles
Simulate system behavior before deployment
Iterate through simulations in a snap
Reduce reliance on hardware availability
Conclusion
Altair Embed is a powerful and efficient real-time model-based embedded system design solution. Graphical modeling, real-time simulation, and automated code generation enable engineers and developers to accelerate the design cycle, improve code quality, and bring products to market faster.
If you are designing embedded software, embedded control systems, robotics, or IoT, then Altair Embed is a necessary tool that will revolutionize the way you design, test, and deploy embedded applications.
